GM50H генератор набор контроллер замена вращающийся скорость цифровой аксессуар тест Многофункциональный измеритель двигателя ABS ЖК-дисплей

Features:
Input frequency is available to check RPM.
Variety of sensor curves' parameters is set inside.
Sensor curve can be self-defined by buttons.
High-light digital tube can demonstrate the parameters. English and demonstration.
The parameters can be set and adjusted by the button on the front face.
Specifications:
Model: GM50
Material: ABS
Color: black
Power supply: DC8~36V
Power consumption: MAX 1W
Sensor input resistance: 0~1000 ohms
Speed input signal frequency range: Freq 300Hz~15kHz
Speed input signal amplitude range: A C 3~16V
Input power generation frequency: Freq 45~70Hz
Input power generation voltage: A C40~280V
Size: (Approx) 100*100*77mm
Installation Size: (Approx) 91*91mm
Package Included:
1 PC x Digital Multi-functional Meter
1 PC x English manual
1 Set x Mounting Screws
Note:
1. Due to the light and screen difference, the item's color may be slightly different from the pictures.
2. Please allow 0.5-2 cm differences due to manual measurement.
